概念

SSL/TLS协议

SSL（Secure Sockets Layer）javassl客户端证书，安全套接字协议javassl客户端证书，是为网络通信提供安全及数据完整性的一种安全协议。SSL主要是使用公开密钥体制和X.509数字证书技术保护信息传输的机密性和完整性，它不能保证信息的不可抵赖性，主要适用于点对点之间的信息传输。

TLS（Transport Layer Security），传输层安全，是IETF在SSL3.0的基础上设计的协议，它是SSL协议的升级版。两者差别极小，可以理解为TLS是 SSL3.1。

TLS与SSL都是在传输层与应用层之间对网络连接进行加密。

单向认证VS双向认证

单向认证，服务端部署SSL证书就行，任何用户都可以去访问（IP被限制除外等），只是服务端提供了身份认证。

双向认证，服务端部署SSL证书，也需要客户端提供身份认证，只有服务端允许的客户端才能访问，安全性相对于要高一些。

SSL单向认证过程、SSL双向认证过程

制作证书

命令制作用于SSL/TSL的证书

#1、服务器端===>生成自签名证书keytool -genkey -dname "CN=localhost" -keysize 2048 -alias server -keyalg RSA -keystore d:/server.jks -keypass 123456 -storepass 123456 -validity 36500#2、服务器端===>从服务器端证书秘钥库中导出Cer证书keytool -export -alias server -keystore d:/server.jks -storepass 123456 -file d:/server.cer#3、客户端==>生成自签名证书keytool -genkey -dname "CN=localhost.client1" -keysize 2048 -alias client1 -keyalg RSA -keystore d:/client1.jks -keypass 123456 -storepass 123456 -validity 36500#4、客户端==>从服务器端证书秘钥库中导出Cer证书keytool -export -alias client1 -keystore d:/client1.jks -storepass 123456 -file d:/client1.cer#5、客户端==>将客户端证书导入到服务器端证书秘钥库keytool -import -trustcacerts -alias server -file d:/server.cer -keystore d:/client1.jks -storepass 123456# 6、服务器端==>将服务器端证书导入到客户端证书秘钥库keytool -import -trustcacerts -alias client1 -file d:/client1.cer -keystore d:/server.jks -storepass 123456# ****查看颁发证书keytool -list -keystore D://server.jkskeytool -list -rfc -keystore d:/server.jks -storepass 123456keytool -list -keystore D://client1.jkskeytool -list -rfc -keystore d:/client1.jks -storepass 123456

代码制作用于SSL/TSL的证书

说明javassl客户端证书：与命令制作一致，内容必须参考javassl客户端证书：生成自签名证书、生成签名证书，注意没有给出maven相应的坐标，这次补上。

Maven（pom.xml）

<dependency> <groupId>org.bouncycastle</groupId> <artifactId>bcprov-jdk15to18</artifactId> <version>1.70</version></dependency><dependency> <groupId>org.bouncycastle</groupId> <artifactId>bcpkix-jdk15to18</artifactId> <version>1.70</version></dependency>

制作证书代码：

package com.what21.netty01.demo01.cert2;import com.what21.netty01.demo01.cert.CreateDataCertificateStore;import com.what21.netty01.demo01.cert.IssueCertificate;import java.io.FileOutputStream;import java.io.OutputStream;import java.security.KeyStore;import java.security.cert.Certificate;public class KeyStoreTest { public static void main(String[] args) { // ===============================================================================// // 1、服务器端===>生成自签名证书 // ===============================================================================// int keyLen = 2048; String alias = "server"; String storePasswd = "123456"; String trustPasswd = "123456"; // 注意顺序 String fullDN = "CN=localhost"; String storePath = "D://localhost_server.jks"; try { OutputStream storeOutput = new FileOutputStream(storePath); CreateDataCertificateStore.generateKeyStore(keyLen, alias, storePasswd, trustPasswd, fullDN, 10, storeOutput); } catch (Exception e) { e.printStackTrace(); } // ===============================================================================// // 2、服务器端===>从服务器端证书秘钥库中导出Cer证书 // ===============================================================================// KeyStoreUtils.KeyStoreParam keyStoreParam = new KeyStoreUtils.KeyStoreParam(); keyStoreParam.setStorePath(storePath); keyStoreParam.setStorePasswd(storePasswd); keyStoreParam.setAlias(alias); keyStoreParam.setTrustPasswd(trustPasswd); KeyStoreUtils.KeyStoreEntry keyStoreEntry = KeyStoreUtils.readToKeyStoreEntry(keyStoreParam); CertUtils.generateCert(keyStoreEntry, "D://localhost_server.cer"); // ===============================================================================// // 3、客户端==>使用服务器端签名证书生成客户端证书 // ===============================================================================// KeyStore.PrivateKeyEntry rootPrivateKeyEntry = null; try { rootPrivateKeyEntry = IssueCertificate.getRootPrivateKey(storePath, storePasswd, alias, trustPasswd); } catch (Exception e) { e.printStackTrace(); } String clientAlias = "client1"; String subjects = "CN=localhost.client1"; String signTrustPasswd = "123456"; int validityYears = 10; String trustPath = "d:/localhost_client1.jks"; try { IssueCertificate.issueCertificate(rootPrivateKeyEntry, clientAlias, subjects, signTrustPasswd, validityYears, trustPath); } catch (Exception e) { e.printStackTrace(); } // ===============================================================================// // 4、客户端==>从服务器端证书秘钥库中导出Cer证书 // ===============================================================================// KeyStoreUtils.KeyStoreParam clientKeyStoreParam = new KeyStoreUtils.KeyStoreParam(); clientKeyStoreParam.setStorePath(trustPath); clientKeyStoreParam.setStorePasswd(signTrustPasswd); clientKeyStoreParam.setAlias(clientAlias); clientKeyStoreParam.setTrustPasswd(signTrustPasswd); KeyStoreUtils.KeyStoreEntry clientKeyStoreEntry = KeyStoreUtils.readToKeyStoreEntry(clientKeyStoreParam); CertUtils.generateCert(clientKeyStoreEntry, "D://localhost_client1.cer"); // ===============================================================================// // 5、客户端==>将客户端证书导入到服务器端证书秘钥库 // ===============================================================================// Certificate clientCertificate = CertUtils.readCert("D://localhost_client1.cer"); try { KeyStoreUtils.importToKeyStore(storePath, storePasswd, "client1", clientCertificate); } catch (Exception e) { e.printStackTrace(); } // keytool -list -keystore D://localhost_server.jks // keytool -list -rfc -keystore D://localhost_server.jks -storepass 123456 // ===============================================================================// // 6、服务器端==>将服务器端证书导入到客户端证书秘钥库 // ===============================================================================// Certificate serverCertificate = CertUtils.readCert("D://localhost_server.cer"); try { KeyStoreUtils.importToKeyStore(storePath, signTrustPasswd, "server", serverCertificate); } catch (Exception e) { e.printStackTrace(); } // keytool -list -keystore D://localhost_client1.jks // keytool -list -rfc -keystore D://localhost_client1.jks -storepass 123456 // ===============================================================================// // The end // ===============================================================================// }}

依赖如下的工具类，没有找到，请到关联的文章中找~

其他工具类：

package com.what21.netty01.demo01.cert2;import lombok.Data;import sun.misc.BASE64Encoder;import java.io.FileInputStream;import java.io.FileOutputStream;import java.security.KeyStore;import java.security.PrivateKey;import java.security.PublicKey;import java.security.cert.Certificate;public class KeyStoreUtils { /** * @param storePath 秘钥库文件路径 * @param storePasswd 秘钥库密码 * @param alias 证书别名 * @param trustPasswd 证书密码 * @return * @throws Exception */ public static KeyStoreEntry readToKeyStoreEntry(String storePath, String storePasswd, String alias, String trustPasswd) throws Exception { KeyStore keyStore = KeyStore.getInstance("JKS"); keyStore.load(new FileInputStream(storePath), storePasswd.toCharArray()); PrivateKey privateKey = (PrivateKey) keyStore.getKey(alias, trustPasswd.toCharArray()); PublicKey publicKey = keyStore.getCertificate(alias).getPublicKey(); Certificate certificate = keyStore.getCertificate(alias); BASE64Encoder encoder = new BASE64Encoder(); String privateKeyEncoded = encoder.encode(privateKey.getEncoded()); String publicKeyEncoded = encoder.encode(publicKey.getEncoded()); KeyStoreEntry keyStoreEntry = new KeyStoreEntry(); keyStoreEntry.setKeyStore(keyStore); keyStoreEntry.setPrivateKey(privateKey); keyStoreEntry.setPublicKey(publicKey); keyStoreEntry.setCertificate(certificate); keyStoreEntry.setPrivateKeyEncoded(privateKeyEncoded); keyStoreEntry.setPublicKeyEncoded(publicKeyEncoded); return keyStoreEntry; } /** * @param storePath * @param storePasswd * @param certAlias * @param certificate * @throws Exception */ public static void importToKeyStore(String storePath, String storePasswd, String certAlias, Certificate certificate) throws Exception { KeyStore keyStore = KeyStore.getInstance("JKS"); FileInputStream keyStoreInput = new FileInputStream(storePath); keyStore.load(keyStoreInput, storePasswd.toCharArray()); keyStoreInput.close(); if (!keyStore.containsAlias(certAlias)) { keyStore.setCertificateEntry(certAlias, certificate); FileOutputStream keyStoreOutput = new FileOutputStream(storePath); keyStore.store(keyStoreOutput, storePasswd.toCharArray()); keyStoreOutput.close(); } } @Data public static class KeyStoreEntry { private KeyStore keyStore; private PrivateKey privateKey; private PublicKey publicKey; private Certificate certificate; private String privateKeyEncoded; private String publicKeyEncoded; } @Data public static class KeyStoreParam { public String storePath = "d:/server.jks"; public String storePasswd = "123456"; public String alias = "server"; public String trustPasswd = "123456"; } /** * @param keyStoreParam * @return */ public static KeyStoreEntry readToKeyStoreEntry(KeyStoreParam keyStoreParam) { try { return readToKeyStoreEntry(keyStoreParam.getStorePath(), keyStoreParam.getStorePasswd(), keyStoreParam.getAlias(), keyStoreParam.getTrustPasswd()); } catch (Exception e) { e.printStackTrace(); } return null; } /** * @return */ public static KeyStoreEntry readToKeyStoreEntry() { String storePath = "d:/server.jks"; String storePasswd = "123456"; String alias = "server"; String trustPasswd = "123456"; try { return readToKeyStoreEntry(storePath, storePasswd, alias, trustPasswd); } catch (Exception e) { e.printStackTrace(); } return null; }}package com.what21.netty01.demo01.cert2;import java.io.*;import java.security.cert.Certificate;import java.security.cert.CertificateFactory;import java.security.cert.X509Certificate;/** * CER = CRT证书的微软型式 */public class CertUtils { /** * 打印证书内容 * * @param x509Certificate * @return */ public static Certificate printInfo(X509Certificate x509Certificate) { System.out.println("读取Cer证书信息..."); System.out.println("x509Certificate_SerialNumber_序列号___:" + x509Certificate.getSerialNumber()); System.out.println("版本号:" + x509Certificate.getVersion()); System.out.println("序列号:" + x509Certificate.getSerialNumber().toString(16)); System.out.println("主体名：" + x509Certificate.getSubjectDN()); System.out.println("签发者：" + x509Certificate.getIssuerDN()); System.out.println("有效期：" + x509Certificate.getNotBefore()); System.out.println("截止日期：" + x509Certificate.getNotAfter()); System.out.println("签名算法：" + x509Certificate.getSigAlgName()); System.out.println("x509Certificate_getIssuerDN_发布方标识名___:" + x509Certificate.getIssuerDN()); System.out.println("x509Certificate_getSubjectDN_主体标识___:" + x509Certificate.getSubjectDN()); System.out.println("x509Certificate_getSigAlgOID_证书算法OID字符串___:" + x509Certificate.getSigAlgOID()); System.out.println("x509Certificate_getNotBefore_证书有效期___:" + x509Certificate.getNotAfter()); System.out.println("x509Certificate_getSigAlgName_签名算法___:" + x509Certificate.getSigAlgName()); System.out.println("x509Certificate_getVersion_版本号___:" + x509Certificate.getVersion()); System.out.println("x509Certificate_getPublicKey_公钥___:" + x509Certificate.getPublicKey()); return x509Certificate; } /** * @param keyStoreEntry * @param cerFile */ public static void generateCert(KeyStoreUtils.KeyStoreEntry keyStoreEntry, String cerFile) { try { FileOutputStream outputStream = new FileOutputStream(cerFile); outputStream.write(keyStoreEntry.getCertificate().getEncoded()); outputStream.flush(); } catch (Exception e) { e.printStackTrace(); } } /** * @param certPath * @return */ public static Certificate readCert(String certPath) { Certificate certificate = null; try { CertificateFactory factory = CertificateFactory.getInstance("X.509"); FileInputStream inputStream = new FileInputStream(certPath); certificate = factory.generateCertificate(inputStream); inputStream.close(); } catch (Exception e) { e.printStackTrace(); } return certificate; } /** * @param args */ public static void main(String[] args) { KeyStoreUtils.KeyStoreEntry keyStoreEntry = KeyStoreUtils.readToKeyStoreEntry(); // 生成cer证书 generateCert(keyStoreEntry, "d://server.g.cer"); // 读取cer证书 Certificate certificate = readCert("d://server.g.cer"); printInfo((X509Certificate) certificate); }}
